Waste Clothing Shredder Leather Scrap Shredder Industrial Solid Waste Shredding and Baling Production Line

core components : PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear

Usage : Wide Usage

Power(W) : 200 kW

Function : High Effieciency

Place of Origin : Henan, China

Weight (kg) : 18000

Model : CR-1660

Voltage : 380 V, 380v/50HZ(as Customers' Request )

Feature : Stability

Brand Name : CR

machinery test report : Provided

Product name : Industrial Solid Waste Shredder

warranty : 1 Year

Price : $42,000-58,000

video outgoing-inspection : Provided

Application : Automation Equipment

Type : Full- Automatic

MOQ : 1

Power : 200kw

Keyword : Easy Operation

Contact Now

Waste Clothing Shredder Leather Scrap Shredder Industrial Solid Waste Shredding and Baling Production Line

◊Industrial Solid Waste Dual-Shaft Shredder

Equipped with a planetary reducer and a branded motor, it features highly reliable performance and low maintenance costs. It is suitable for processing various materials such as industrial solid waste, metals, scrap steel, scrap aluminum, tires, plastics, and wood. Through the working principle of dual-shaft shearing and extrusion, it achieves efficient and precise processing of materials. This shredder has the characteristics of low speed and high torque, which can significantly reduce dust, lower labor consumption, and ensure stable and reliable operation of the equipment. Depending on the material and the final required size, it can be equipped with different components or used in conjunction with shredders of other stages to crush materials to the desired size.

◊Advantages

Using the CR series shredders enables more efficient shredding operations. These low-speed industrial shredders have strong shredding capabilities and higher versatility.

★ It can effectively shred large pieces of waste, doubling the output of crushing and sorting processes. ★ Equipped with a PLC control system, automatic overload protection, and an automatic reverse switch. ★ The low-speed design ensures extremely low noise during operation and minimal dust generation. ★ It has energy-saving features, and is very convenient in installation, operation, and maintenance.

Working Principle

1. Feed Hopper: Put the material to be crushed, so as to prevent the material from splashing out;

2. Double Shaft Cutting System: Using different blades according customers' material;

3. Power System: We choose famous brands of motor in China, can also be configured according to customer needs;

4. Discharging Conveyor System: It adopts independent power system, and that power system is integrally fixed on the shredder by bolts, so that the power system can be integrally drawn out.

01 Motor

We use domestic motor manufactured by Chinese-famous suppliers, but you can choose Siemens or other brand motor. Don't worry about our machine's quality.

02 Planetary Gearbox

High torque, low noise, steady performance. Greater power transmission efficiency, compact and efficient load distribution, light-weight and high-power density, accurate results & stability and enhanced life-span.

03 Shredder box body

The split type design makes the overall structure of the shredder more compact, lightweight, occupies less space, is easy to install and fix, and can achieve efficient crushing operations in limited space. The split design makes the shredder more convenient to maintain.

04 PLC control cabinet

Shredder control cabinets adopts PLC control, Shneider and Siemens electrical components for options, automatically reverse when overload.

05 Blades

Blades made of high hardness alloy: 55Crsi//M6v/H13 for options, according to different material processing, different blade shape, thickness and cutting head quantity providing the optimum solutions

Model	Blade diameter	Spindle diameter(mm)	Reducer model	Motor	LWH(mm)	Weight（KG）
600	220mm	120mm	ZQ400*2	11KW*2	240012001800	2000
600	260mm	140mm	ZQ500*2	18.5KW*2	270014001900	2600
800	260mm	140mm	ZQ500*2	18.5KW*2	320017002200	3300
800	800	400mm	180mm	ZQ650*2	30KW*2	380018002200	5200
8040	400mm	180mm	ZSY280*2	30KW*2	400019002400	6500
1000	400mm	180mm	ZQ750*2	37KW*2	400021002400	7000
1000	1000	400mm	180mm	ZQ850*2	45KW*2	420021002600	10000
1040	450mm	180mm	ZSY315*2	37KW*2	420021002400	9000
1245	450mm	220mm	ZSY355*2	45KW*2	450022002700	10000
1550	500mm	270mm	ZSY400*2	55KW*2	480022002800	13000
1855	550mm	280mm	ZSY450*2	75KW*2	560022003000	17000
2060	600mm	300mm	ZSY500*2	110KW*2	600022003200	20000

NOTE:

1.The above shredder is our standard configuration.

2. The number of blade claws, diameter, and thickness can be customized according to the type of material and the size of the discharge.

3. More information please contact us, we can custom the product on your request.

We are factory, Please contact us to arrange a factory visit for you.

Zhengzhou Chenrui Machinery Equipment Co., Ltd. Located in the High-End Equipment Manufacturing Park, Zhanjie Town, Gongyi City,Zhengzhou, Henan Province.

As one of the manufacturers of waste and other solid waste metal recycling equipment with 21years of production experience, our factory can provide a complete set of solutions. All products are equipped with a perfect after-sales service system and hold CE certification. If assistance is needed, we can dispatch engineers overseas to provide equipment installation and operation training services.

Chenrui Machinery possesses a professional R&D team and a complete sales and service system. Currently, its advanced equipment has been exported to the United States, Mexico, Malaysia, South Korea, Japan, Spain, Turkey, Italy, Vietnam, South Africa, Australia, Singapore, India, the Philippines, Zambia, Thailand, Saudi Arabia, the United Arab Emirates and other countries and regions.

We are factory, Please contact us to arrange a factory visit for you.

Q: Why Choose Us? （1）15 years of manufacturing experience We have rich experience in equipment manufacturing. Our machines have high reputation both at home and abroad (Such as the Middle East, Southeast Asia, Africa and so on more than 10 countries and regions.) （2）Manufacturer, Not Dealer Factory direct sale makes price more competitive.Customers are always welcome to visit our factory for machine test. （3）Fast Delivery We promise the goods can be shipped out on delivery date after confirmation of the order. Q: How do I know the quality of your machine? A: You can send your sample scrap materials to us and we will test the machine for you without charging the fees. And we can send the machine test video to you. We also warmly welcome you to visit our factory to test our machine personally. Q: When we only purchase one shredder machine production line, can we use it to shred other scrap materials like? A: Yes, you can.It depends on the difference of blades teeth and quantity, which can be customized. Q: Which brand of motor will you use? A: We use domestic motor manufatured by Chinese-famous suppliers, but you can choose Siemens or other brand motor. Don't worry about our machine's quality. Q: Will you dispatch the engineer to guide installation? A: Yes, according to the customer's requirement, we will dispatch engineers to guide installation and traning about the operation
