Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners

Product Categories
Zhengzhou Chenrui Machinery Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners

After-sales Service Provided : Video Technical Support

MOQ : 1

plastic type : PVC, PET, ABS, PP/PE, PE, PP, PC, PMMA, PA, PS

video outgoing-inspection : Provided

Machine Type : Plastic Shredder

Function : Plastic Cutter Grinder Crusher Shredder Machine

weight (t) : 0.8

dimension(l*w*h) : 1200mm*1100mm*1650mm

key selling points : Competitive Price

power (kw) : 15

Raw material : PP PE ABS PC PET

warranty : 1 Year

Brand Name : CR

voltage : 220V/380V(or customized)

Price : $1,700-1,800

core components : Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Other

Crushing material : General Plastic Materials

Keyword : Plastic Shreeder

shaft design : Single

Usage : Waste Raw Material Shredding

Place of Origin : Henan, China

use : Waste Plastic Crusher

Application : Recycle Waste Plastic

machinery test report : Provided

Name : Waste Palstic Crushing

Contact Now

Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners

■Plastic crusher machine

Plastic crushers are used to crush waste plastics and plastic scraps from factories. Plastic crushers are widely used in the regeneration of waste plastics and the recycling and reuse of factory scraps.
The plastic crusher is driven by an electric motor to rotate the moving knife disc at high speed. During the high-speed rotation of the moving knife, it forms a tendency of relative motion' with the fixed knife. The gap formed between the moving knife and the fixed knife creates a cut for plastic crushing and shearing, there by breaking down large pieces of plastic. The crushed plastic is filtered through a screen to determine the size of the plastic particles and then output.

■Advantage

The crusher is easy to operate, and the knife change is simple and quick. The tool rest is optimized in design. The claw-shaped knife can disperse the force received, increasing the shearing force of each knife piece. It is suitable for crushing thick materials, hard material blocks, material heads, etc., effectively enhancing the cutting force of the tool and reducing tool wear. It is equipped with an electric control safety design. The hopper adopts a double-layer structure and is filled with sound insulation materials inside, which makes the equipment have good safety and environmental protection, energy-saving and durable.
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
01/Motor
Pure copper motor, excellent electrical conductivity, good thermal conductivity, corrosiveness,suitable for a variety of working environments.
02/Sieve mesh
Screens of different specifications can be replaced according to different needs to achieve the required material size.
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
03/Rotor
The blades are made of alloy materials (such as 55SICR,SKD-11, etc.), which have stronger wear resistance and a longer service life.
04/Hydraulic pump station
The hydraulic power can be quickly installed without the cumbersome disassembly process, which is convenient for maintenance, reduces manpower and downtime, and improves the operational efficiency of the equipment.
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Lightweight (decorative blade)
Model
Power(kw)
Output(kg/h)
External dimensions(mm)
Machine weight(kg)
400
7.5
200-400
1100×800×1000
400
600
15
400-800
1200×1100×1650
800
800
30
800-1200
1700×1400×2000
1500
1000
45
1000-1500
1950×1900×2200
2000
1200
55
1500-2000
2200×2100×2200
2300
1500
75
2000-3400
2500×2300×2200
2800
1600
90
3000-6000
2600×2400×2300
3200
High-pressure heavy-duty plate cutter (herringbone blade)
Model
Power（kw）
Output （kg/h）
External dimensions（mm）
Machine weight（kg）
400
15
300-500
1100×800×1000
600
600
30
600-1000
1200×1100×1650
1200
800
45
900-1600
1700×1400×2000
2000
1000
55
1200-1800
1950×1900×2200
2500
1200
75
1600-2500
2200×2100×2200
3000
1500
90-110
3000-5000
2500×2300×2200
3500
1600
110-132
3800-6500
2600×2400×2300
4000
High-pressure heavy-duty tooth cutter (claw cutter)
Model
Power (kW)
Output (kg/h)
External dimensions（mm）
Machine weight（kg）
400
18.5
300-500
1100×800×1000
600
600
30
600-1000
1200×1100×1650
1200
800
37
900-1600
1700×1400×2000
2000
1000
45
1200-1800
1950×1900×2200
2500
1200
55
1600-2500
2200×2100×2200
3000
1500
55
3000-5000
2500×2300×2200
3500
1600
75
3800-6500
2600×2400×2300
4000
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners

About Us

Zhengzhou Chenrui Machinery Equipment Co., Ltd. was established in 2007. Our factory is located in the High-End Equipment Manufacturing Park, Zhanjie Town, Gongyi City, Zhengzhou City, Henan Province. We design and manufacture industrial shredders, waste tire recycling equipment, waste metal recycling machinery, and waste home appliance crushing and sorting production lines, etc. Our products have obtained ISO and CE certifications and have been widely exported to over 30 countries, receiving high praise from customers. Over the years, we have continuously improved and researched, developing various new products that sell well both at home and abroad, earning a good reputation and corporate image. We are always committed to providing better quality and service. Welcome your inquiries!
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Plastic Lump Crusher - Crushes HDPE PP Hard Plastic Scrap & Injection Molding Runners
Q: What is the maximum processing capacity of this crusher? Can it operate continuously?
‌A‌: Our industrial-grade shredder has a continuous processing capacity of 6500 kg/h, utilizing reinforced steel blades and a heavy-duty motor. It maintains stable performance even when processing high-density materials such as PVC pipes and ABS sheets, making it ideal for continuous operation in recycling plants.
Q: Can it process mixed plastics? For example, waste materials containing a mixture of PP, PE, and ABS.
A: Absolutely! Our shredder is specifically designed for mixed plastics, and its alloy steel blades efficiently separate and shred the materials, making it an ideal choice for recycling centers dealing with complex waste streams.
Q: Is it complicated to operate? Does it require professional training?
A: The design is very user-friendly, equipped with an intuitive control panel. We provide free online video tutorials and operating manuals, and most customers find it easy to get started.
Q: Is maintenance difficult? How often do the blades need to be replaced?
A: Maintenance is very simple; just perform regular inspections. The blade life is typically 6-12 months (depending on usage frequency and materials), and as a consumable part, we will provide replacement blades at a discounted price.
Q: Do your machines have CE certification? Do they comply with EU environmental standards?
A: Yes, our shredders are CE certified and RoHS compliant, equipped with a dust suppression system, and the noise level is kept below 75 decibels, fully meeting EU environmental requirements.
Q: Can the product be customized to my needs? For example, can the production capacity or color be adjusted?
A: Absolutely! We support OEM customization and can adjust the product according to your production capacity requirements, voltage specifications, or color preferences.
